HiCAD Reality Studio

> Save as... > 3-D formats (Step...)

This function enables you to export your current drawing as a TGF file: Select either

Click the ISD Button and select Save as... > 3-D formats (Step...), or
activate the Drawing tab and select Save/Print > SaveAs > 3-D formats (Step...).

In the dialogue window for the saving of the file, select HiCAD Reality Studio (.tgf) from the Save as type listbox.

This file can then be processed by HiCAD's 3-D Reality Studio.

To open TGF files saved to the drawing directory, in HiCAD's 3-D Reality Studio you need to call the Load drawing function.
