HiCAD Sheet Metal (3-D SM)

Today, sheet metal processing stands for state-of-the-art production technologies and materials. Whereas casings, facade sheets, vessels and pipes once consisted of several components, it is now possible to create complex sheet bend parts from one single piece.

This increase in complexity is causing sheet metal processing to move towards 3-D construction, be that for graphical visualisation, early checking of the functionality or for technical production reasons.

HiCAD Sheet Metal, our universal and completely integrated solution for sheet metal processing, provides optimum support for these changes in requirements and offers a high degree of streamlining potential.

Sheet metal-specific functions, state-of-the-art technologies and a wide range of automatic procedures ensure that the route to the finished sheet model is significantly shortened.

The actual construction of the sheet is only one step along this route. To save time , reduce costs and improve product quality, the entire production process from the concept to the finished sheet metal product must be streamlined and standardized. Besides industry-specific construction tasks, HiCAD therefore also takes into account the various production technologies.
